SS 409L Sheets, 1-2 Mm and 3-4 Mm, Cold Rolled 409L Stainless Steel Sheet, Thickness: 2-3 mm, SS 409L 2B, 2D, Surface Finish, Stainless Steel Sheet Plate 409 L, EN 1.4512, AISI 409L, UNS S40900, Ready Stock from ISO Jindal / POSCO / SAIL / Imported.
SS 409L PLATE / SS 409L SHEET / SS 409L COILS / SS 409L STRIPS
Stainless Steel 409L (UNS S40900, EN 1.4512) is a kind of stabile version of 409, composed with proper chromium, low composition of carbon and nitrogen and adjunction of titanium, all composition appropriate make Grade 409L products have some properties, Corrosion Resistance, Weldability and Formability. Due to the lower chromium, Grade 409L was another low cost option for corrosion resistant stainless steel.
Grade 409L has a good combination of Heat Resistance and Corrosion Resistance, can be ideal for non- or lightly corrosive environments or applications. It has excellent oxidation resistance in high temperatures and good welding performance, which can be used for automotive exhaust pipes or oil equipment.
Grade 409L may be considered for a wide variety of applications where one or more of the following properties are important:
| Item Name | : | Stainless Steel 409L Plate / Sheets /Coils |
| Steel Grade | : | SS 409L |
| Specification | : | ASTM A240 |
| Standard | : | ASTM, AISI, SUS, JIS, EN, DIN, GB, ASME |
| Mill/Brand: | : | Posco, Jindal, SAIL, Imported Etc. |
| Thickness | : | 0-1 mm, 1-2 mm, 2-3 mm, 4-5 mm, and above 5mm also. |
| Width | : | 1000 / 1219 / 1250 / 1500 / 1800 (mm) |
| Length | : | 2000 / 2438 / 2500 / 3000 / 6000 (mm) |
| Surface Treatment | : | Hot Rolled, Cold Rolled |
| Surface Finish | : | No.1, 2B mill finish, BA bright annealed, #4 finish brushed, #8 mirror, |
| : | Checker Plate, Diamond floor sheet, HL hairline, Grey/dark hairline | |
| Protective Film | : | PVC protective film |
| Stock Size | : | All Sizes in Stock Available |
| Services | : | Cut to Sizes as Custom's Request / Client Requirement |
| Type | : | Plates, Sheets, Coils, Strips, Flats Etc. |
| Sheet Size | : | 4 ft X 8 ft, 5 ft X 10 ft (feet X feet) |
Properties of Stainless Steel 409L Grades :
- Corrosion resistance
- Resistance to oxidation
- Excellent resistance to high temperature
- Exhaust gas
- Atmospheric Corrosion
- Heat treatment
- Suitable for welding
- Good flexibility
- Excellent formability
- Low costs
Ex Stock in hand / Ready Stock :
| POSCO HR Stainless Steel 409 L Grade Sheet / Coil in Ex-Stock. | ||
| Thickness | Width | Length |
| 3 mm | 1250 mm | As per Requirement |
| 4 mm | 1250 mm | As per Requirement |
| 5 mm | 1250 mm | As per Requirement |
| 6 mm | 1250 mm | As per Requirement |
| 8 mm | 1250 mm | As per Requirement |
For Current availability Status or inquiry or RFQ for your enquiry email us at
Date Sheet for Stainless Steel 409L / SS409L :
Chemical Composition / Chemistry of SS 409L Grade
Designation | %C | %Mn | %P | %S | %Si | %Cr | %Ni | %Mo | N PPM | %Others |
| (min~max) | (min~max) | (min~max) | (min~max) | (min~max) | (mim~max) | (min~max) | (min~max) | (max) | ||
| Ferritic | ||||||||||
| SS 409 | 0.03 | 1 | 0.04 | 0.02 | 1 | 10.50-11.70 | 0.50 max | Ti -6X (C+N) Min., 0.5 Max. | ||
| SS 409L | 0.03 | 1 | 0.04 | 0.03 | 1 | 10.50-11.70 | 0.50 max | - | 300 | Ti =6X (C+N) Min., 0.75 Max. |
Mechanical Properties of SS 409L
Designation | Tensile Strength (MPA)min. | %Yield Strength(MPA)min. | %Elongation(min.) | Hardness (HRB)max. |
| Martensitic | ||||
| SS 409 | 380 | 170 | 20 | 88 |
| SS 409L | 380 | 170 | 20 | 88 |
Product Applications & Usage:
Automotive exhaust systems (manifolds, exhaust pipes, converters, front and tail pipes, converters, mufflers and other components)
- Heat exchangers
- Catalytic converter systems
- Culverts
- Home heating systems
- Automotive thermostats
- Fuel filters
- Farm equipment components
- Electrical transformer cases
- Paper & Pulp Companies
- High Pressure Applications
- Oil and Gas Industry
- Chemical Refinery
- Pipeline
- High Temperature Application
- Water Pipe Line
- Nuclear Power Plants
- Food Processing and Dairy Industries
- Boiler & Heat Exchangers
Specifications of Grade 409L :
- ASTM A240M – Chromium and Chromium – Nickel Stainless Steel Plate, Sheet and Strip for Pressure Vessels and for General Applications.
- ASTM 480M – General Requirements for Flat Rolled Stainless and Heat-Resisting Steel Plate, Sheet and Strip
- EN 10088-2 (1.4512) – Stainless Steel Technical delivery conditions for sheet, plate and strip of corrosion resisting steels for general purposes
Specifications :
The following specifications cover Stainless Steel 409
- AISI 409
- ASTM A176
- ASTM A240
- ASTM A268
- ASTM A791
- ASTM A803
- DIN 1.4512
- DIN 1.4720
- UNS S40900
Product Forms for SS 409L :
- Coil
- Plates
- Sheet
- Strip
Feather and Applications of SS 409L :
409L Stainless Steel is ultra low carbon ferritic stainless steel, it has good oxidation resistance, good welding performance, excellent corrosion resistance, suitable for the lightweight, extend the life of the car and bus, it’s widely used in automobile exhaust system components
Specifications of 409L Stainless Steel :
409L Stainless Steel Sheet, cold rolled 2B surface SS 409L Sheet / Plate
SS409L / S40903 is ultra low carbon ferritic stainless steel, steel has good oxidation resistance, good welding performance.
Ferritic Stainless Steel SS 409 L / 409 :
| EN Designations | ASTM Designation |
| 1.4512 | 409L |
| X2CrTi12 | S40910 |
Welding :
The recommended consumable electrodes are the following.
| Shielded Electrodes | Wires and Rods | Hollow Electrodes |
| E 19 9 L | G 19 9 L (GMAW) | T 13 Ti |
| W 19 9 L (GTAW) | ||
| P 19 9 L (PAW) | ||
| ER 308L | S 19 9 L | ER 308L |
| ER 208 L |
Tests we carry out (including both Destructive and Non-Destructive) as per Customer Requirements :
- Positive material recognition
- Mechanical examining like tensile, Elongation and reduction of area.
- Large-scale test
- Chemical examination-Spectro analysis
- Firmness test
- Pitting protection test
- Small tests
- X-ray test
- Impact analysis
- Eddy current examining
- Hydrostatic analysis
- Prompt test
Types of Stainless Steel 409L / SS409L Plates / Sheets :
| SS 409L Plates | SS 409L Sheets |
| SS 409 Plates | SS 409 Sheets |
| SS 409L Coil | SS 409L Strips |
| Stainless Steel 409L Plates | Stainless Steel 409L Sheets |
| Stainless Steel 409L Coils | Stainless Steel 409L Strips |
| UNS40900 Plates | UNS40900 Sheets |
| UNS40900 Coil | UNS40900 Strips |
| EN 1.4512 Plates | EN 1.4512 Sheets |
| EN 1.4512 Coil | EN 1.4512 Strips |
| ASTM A240M | ASTM 480M |
| Jindal SS409L Plates | POSCO SS409L Sheets |
| Jindal SS409L Sheet | POSCO SS409L Plates |
| Jindal SS409L Coils | POSCO SS409L Coils |
| Jindal SS409L Strips | POSCO SS409L Strips |
