XAR 500 Plate
We NEW ARISE METAL bring froth an impregnable range of Wear Resistant Steel-XAR 500. Wear-resistant steel with average hardness of 500 HB.
XAR is available in various grades from 300 HBW to 600 HBW and plate thicknesses from 1/6” to 4” (4 to 100 mm), tailored to particular applications, e.g. Mining Equipment, Earthmoving Machinery, Steel Mill and Cement Plant Equipment, Agricultural Machinery, etc.
XAR 400, XAR 450 and XAR 500 plates can also be supplied as cut-to-length plates in thicknesses up to approx. 3/8” (10 mm).
Properties of XAR 500 Plates / Sheet :
- Hardnesses up to 600 Brinell
- At least five times the service life of conventional structural steel
- Ideal for press braking and bending
- Good welding and cutting properties
Scope of XAR 500 Plates / Sheet:
This material specification applies to 3mm to 100mm thick plates of the wear resistant special structural steel XAR 500.
Material number : 1.8734
Application of XAR 500 Plates / Sheet:
The steel may be used at the discretion of the purchaser for wear-exposed structures, e.g. excavating, mining and earth-moving machinery, truck dump bodies, conveying, crushing and pulverizing equipment, scrap presses and paving molds. The processing and application techniques as a whole are of fundamental importance for the successful use of the products fabricated of this steel. The processor/fabricator must assure himself, that his design and work methods are appropriate for the material, are state-of-the-art and are suitable for the envisaged purpose. The selection of the material is left up to the purchaser.
Overview of XAR 500 Plates / Sheet:
XAR 500
- Sheet thickness 4 – 100 mm
- Brinell hardness 470 – 530
- Size 2000 mm X 6000 mm
This steel, which is even more resistant to loads, is particularly suitable for forming and welding.
Cold forming of XAR 500 Plates / Sheet:
The products made of this steel are suitable for cold bending provided, that consideration is given to the high hardness. The formability of steel decreases with increasing hardness. This has to be kept in mind when forming. The forming must take place at a slow and steady rate, the cut edges must be deburred and the plates heated, if necessary, prior to the forming. A final stress-relieving is not necessary for this steel.
Machinability of XAR 500 Plates / Sheet:
In spite of its high wear resistance, the steel exhibits good machinability if sufficiently heavy machine-tools and sharp carbide-tipped tools are used. The feed rate and cutting speed have to be adjusted to the high hardness of the material.
Applications of XAR 500 Plates / Sheets:
The steel may be used at the discretion of the purchaser for wear exposed structures
- Excavating
- Mining
- Earth Moving Machinery
- Truck Dump Bodies
- Conveying
- Crushing
- Pulverizing Equipment
- Scrap Presses
- Paving moulds
- Switch Manufacturing
- Cement Plant Equipment
- Agricultural Machinery
The Processing and application techniques as a whole are of fundamental importance for the successful use of the products fabricated of this steel. The Processor / Fabricator must assure himself that his design and work methods are appropriate for the material are state of the art and are suitable for the envisaged purpose.
Other Products of XAR STEEL :
- XAR 300
- XAR 400
- XAR 400 PREMIUM
- XAR 400 W
- XAR 450
- XAR 450 PREMIUM
- XAR 500
- XAR 500 PREMIUM
- XAR 600
- XAR HT
Wear-resistant steel
Thanks to their extreme hardness and toughness, XAR heavy plates last at least five times longer than conventional structural steel.
