En19 Plate Stockist, Supplier, Trader, Dealer, Exporter & Manufacturer
The EN19 Grade Steel Plates /Sheets that we offer exactly match the desirable plates of such kinds. It is of the best quality and endowed with high tensile strength. We are working in full throttle to make it available to the length and breadth of the country and abroad. We are one of the eminent Exporters, Stockiest and Suppliers of EN19 Plates / Sheets from Mumbai, India.
NEW ARISE METAL is a leading EN19 Plate Supplier, EN19 Plate Stockiest and EN19 Plate Exporter. EN19 also referred as 708M40 / 709M40 / 40Cr4Mo3 / 40Cr4Mo3 and AISI 4140 comes regarded in the toughened as moved or even T condition. We can offer EN19 Plate in widths, squares, and pads from stock. It is fame for its wear resistance properties and where high quality properties are required. Suitable for apparatuses, shafts, axles, and so forth. These Steel Plates EN-19 Grade find boundless application in different commercial enterprises, for example, vehicles fabricating, Defence, pressing vessels and compartment and development segment, among others. Our scope of Steel Plates EN-19 Grade is accessible at most focused costs.
At our stockyard / warehouse in Kalamboli, Taloja, Navi Mumbai, Maharashtra, INDIA Steel Plates are available in a wide range of special metal grades like Manganese Steel, Alloy Steel, and Stainless Steel in numerous specifications. All Steel Plates Stocks are held to ASME, ASTM, EN, and API , Steel Plates are always available in surplus stock up to 15 metres long, 4 metres wide, and 300 millimetres thick. We are able to offer a solution to virtually any sourcing problem about Steel Plates.
NEW ARISE METAL is the only supplier of EN19 Grade Steel Plate, Hardox 400 Plate, Abrex 400 Steel Plate, Wear Resistant Steel, Sailhard Tiscral Las 07 Plate, AR 400 Plate, High Manganese Plate, Hard field Manganese Plate, Welten 780E Plate in India.
Typical applications of EN19 / 709M40 / 40Cr4Mo3 grade steel:
- Axle shafts
- Crankshafts
- Gears
- Induction hardened pins
- Tooling
- Machine plates
- Shafts
- Sprockets
- Special Machine Parts Molds
- Metal Stamping
- Tool & Die
- Shredders
Equivalent Grades of EN19 Plate & Sheets / 42CRMO4 Plates & Sheets:
| Internal Standard | BS 970 1955 EN | BS 970 1991 | Din | DIN | IS | EN | SAE/AISI | Werkstoff |
| EN 19 | EN19 | 709M40 | 42CrMo2 | 42CrMo4 | 40Cr4Mo3 | EN19 | 4140, 4142 | 1.7225 |
Chemical Composition of EN19 Plate & Sheets / 42CRMO4 Plates & Sheets:
| Element | Min | Max |
| Carbon, C | 0.35 | 0.0045 |
| Manganese, Mn | 0.5 | 0.008 |
| Silicon, Si | 0.1 | 0.0035 |
| Nickel, Ni | ----- | ----- |
| Molybdenum, Mo | 0.2 | 0.004 |
| Chromium,Cr | 0.9 | 0.015 |
| Sulfur, S | ----- | 0.05 |
| Phosphorous, P | ----- | 0.05 |
Stocks Available with us of EN19 Plates & Sheets :
| EN19 Plates 5 mm X 1250 mm X 5000 mm | EN19 Plates 80 mm X 1250 mm X 5000 mm |
| EN19 Plates 10 mm X 1250 mm X 5000 mm | EN19 Plates 85 mm X 1250 mm X 5000 mm |
| EN19 Plates 15 mm X 1250 mm X 5000 mm | EN19 Plates 90 mm X 1250 mm X 5000 mm |
| EN19 Plates 20 mm X 1250 mm X 5000 mm | EN19 Plates 95 mm X 1250 mm X 5000 mm |
| EN19 Plates 25 mm X 1250 mm X 5000 mm | EN19 Plates 100 mm X 1250 mm X 5000 mm |
| EN19 Plates 30 mm X 1250 mm X 5000 mm | EN19 Plates 105 mm X 1250 mm X 5000 mm |
| EN19 Plates 35 mm X 1250 mm X 5000 mm | EN19 Plates 110 mm X 1250 mm X 5000 mm |
| EN19 Plates 40 mm X 1250 mm X 5000 mm | EN19 Plates 115 mm X 1250 mm X 5000 mm |
| EN19 Plates 45 mm X 1250 mm X 5000 mm | EN19 Plates 120 mm X 1250 mm X 5000 mm |
| EN19 Plates 50 mm X 1250 mm X 5000 mm | EN19 Plates 125 mm X 1250 mm X 5000 mm |
| EN19 Plates 55 mm X 1250 mm X 5000 mm | EN19 Plates 130 mm X 1250 mm X 5000 mm |
| EN19 Plates 60 mm X 1250 mm X 5000 mm | EN19 Plates 150 mm X 1250 mm X 5000 mm |
| EN19 Plates 65 mm X 1250 mm X 5000 mm | EN19 Plates 175 mm X 1250 mm X 5000 mm |
| EN19 Plates 70 mm X 1250 mm X 5000 mm | EN19 Plates 200 mm X 1250 mm X 5000 mm |
| EN19 Plates 75 mm X 1250 mm X 5000 mm | EN19 Plates 250 mm X 1250 mm X 5000 mm |
Application Industries of EN19 Plate & Sheets / 42CRMO4 Plates & Sheets:
Automotive, Oil & Gas Industries, Machine Shop, Paper Mills
En Series/ EN19 Steel Plate Company , En Series/ EN19 Steel Plate Wholesaler, En Series/ EN19 Steel Plate Wholesale, En Series/ EN19 Steel Plate Suppliers, En Series/ EN19 Steel Plate Manufacture, En Series/ EN19 Steel Plate Distributors, En Series/ EN19 Steel Plate seller, En Series/ EN19 Steel Plate Stockiest, En Series/ EN19 Steel Plate Bulk Distributors, En Series/ EN19 Steel Plate supplies, En Series/ EN19 Steel Plate exporters.
Applications of EN19 Plate & Sheets / 709M40 / 42CRMO4 Plates & Sheets:
EN19 was originally introduced for the use in the machine tool and motor industries for gears, pinions, shafts, spindles and the like. Later its applications became much more extended and it is now widely used in areas such as the oil and gas industries. EN19 is suitable for applications such as gears, bolts, studs and a wide variety of applications where a good quality high tensile steel grade is suited.
Forging of EN19 Plate & Sheets / 709M40 / 42CRMO4 Plates & Sheets:
Pre heat carefully, then raise temperature to 850-1200oC for forging. Do not forge below 850oC. After forging cool slowly in still air.
Hardening of EN19 Plate & Sheets / 709M40 / 42CRMO4 Plates & Sheets:
This steel grade is commonly supplied ready heat treated. If further heat treatment is required annealed EN19 should be heated slowly to 860-890oC and after adequate soaking at this temperature quench in oil. Temper as soon as tools reach room temperature.
Tempering of EN19 Plate & Sheets / 709M40 / 42CRMO4 Plates & Sheets:
Heat carefully to a suitable temperature selected by reference to a tempering chart or table. Soak at the temperature for 2 hours per 25mm of ruling section, and then allow cooling in air. Tempering between 250-375oC is not advised as tempering within this range will reduce the impact value.
Heat Treatment of EN19 Plate & Sheets / 709M40 / 42CRMO4 Plates & Sheets:
Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of EN19T alloy steel.
