S50C Carbon Steel Plate Stockist, Supplier & Exporter.

S50C Carbon Steel JIS G4051 for Mechanical Structural Use.

Carbon Steels have Lower carbon content than Carbon Tool Steels, and have less strict regulations on impurities. They are used in applications that require a certain amount of strength and toughness.

Carbon steels with low carbon content offer better raw-material workability, but are susceptible to uneven quenching, so care must be taken with regard to temperature management, cooling methods, and the like.

There are many Grades under Carbon Steel some of them are mentioned below.

• Carbon Steels - S15C, S45C, S50C, S55C, and S60C
• Carbon Tool Steels - SK2, SK4, SK5, SK6, and SK7

1. S50C Carbon Steel is steel grade in standard JIS G4051 :

JIS S50C Steel Grade is one steel grade material in JIS G4051, which is standard specification of carbon steels for Machine Structural use, such as Hot Rolling or Hot Forging Tool Steels.

2. JIS S50C Carbon Steel Supply Range :

S50C-Cr steel is suitable for shafts studs, keys etc. and S50C Steel materials are available as rolled or normalized delivery condition as per different customer requirements. We are professional JIS S50C Machinery Steel Supplier and manufacturer. We are able to supply steel S50C Plates, Sheets, Block, square bar, or S50C round steel bar or S50C steel flat, as below range:

S50C Steel Round Bar: 8mm-1600mm

S50C Steel Cold Drawn Bar: 5mm-70mm

S50C Steel Plate: 10 mm to 200 mm Thickness, Width 1500mm – 2500 mm, Length 3000 mm – 6000 mm

3. JIS S50C Carbon Steel Equivalents :

There are some other steel standards and steel grades similar and equivalent to JIS S50C Carbon Steel Grade, as shown below:

• BS EN 10083 C50E/1.1206,
• ASTM A29, 1050
• EN-8 / BS 970 080M50

4. S50C Carbon Steel Properties :

Steel S50C Chemical Composition

JIS S50C Steel Mechanical Properties

5. JIS S50C Carbon Steel Hardness

• Annealed, 179-235 HB
• Tempered, 16-29 HRC

6. Heat Treatment of JIS S50C Steel

JIS S50C Steel materials could be hardened by water quenching at 810-860 degree, and tempered by rapid quenching 550-650 degree

7. Application of JIS S45C Carbon Steel Materials

JIS S50C grade carbon steel is widely used in machinery manufacturing, good mechanical properties of this steel.
S50C carbon steel are generally use to make mechanical parts, like spring, gear, tension bar, the roller, the axis, the load spindle etc.

Standards :

JIS G4051 Grade S50C

Equivalent standards :
