16Mo3 Steel Plate Stockist, Supplier & Exporter
16Mo3 Steel is a pressure vessel steel that is used in applications with elevated temperatures according to EN 10028–2. It has improved mechanical properties and better creep resistance allowing it to be used up to 500°C. This makes it ideal for a wide range of uses where the plates will have to perform at a high temperature continuously. NEW ARISE METAL is leading 16Mo3 Steel Plate stockiest in India
Typical applications for 16Mo3 include a wide range of Power Plant Equipment, Industrial Exhaust, Venting and Flare Systems and Waste Recycling And Incineration Plants. It is also valuable for machinery where parts are likely to remain hot for an extended period. we are exporter of 16Mo3 Steel Plate in India
New Arise Metal is a leading Manufacturer, Trader, Stockist and Supplier of 16Mo3 Plates. We devise a range of products including 16Mo3 using high-quality raw materials, which makes them reliable and durable.
Our 16Mo3 plates are EN 10028 specified pressure vessel grade alloys of Chrome Molybdenum Steel. These products find applications in elevated temperature conditions. The materials is known for its good wear & tear resistance, corrosion resistance, good welding properties, and good tensile, as well as yield strength. The steel type is high weld-able and is used in the fabrication of Industrial Boilers and steel pressurized vessels, which are commonly found in oil, chemical and gas industries. Our products are known to provide amazing usability in all kinds of environmental use.
We deliver our high quality products to a range of industries worldwide. Our products are highly demanded for the robust built and utility that they provide in all usable conditions effectively.
16Mo3 Steel for is used for boilers and pressure vessels with elevated temperatures according to EN 10028–2 (2003). It is equivalent to 15Mo3 (DIN 17155 – Germany), 15D3 (NFA 36–205 – France), BS1501–243b (BS1501 – UK) and ASTM 204 Gr.B.
New Arise Metal Stocks 16Mo3 – ASTM 204 B – in lengths of 4000mm, 6000mm, 8000mm and 12000mm. Widths are either 2000mm or 3000mm and thicknesses are from 2mm to 250mm.
What is 16Mo3 Steel Plate ?
16Mo3 steel plate/sheet, EN10028 16Mo3 steel plate/sheet, under EN10028 standard, we can regard 16Mo3 steel plate/sheet for boiler steels.16Mo3 steel plate/sheet is one mainly of Steel for boiler steels.EN10028 16Mo3 steel is mainly used for boilers and pressure vessels with elevated temperatures equivalent to DIN17155 15Mo3 and UNI5869 15M03, 15D3 (NFA 36205 ) and ASTM A204Gr.B.
New Arise Metal is supplier of 16MO3 Steel Plate in India. We supply 16MO3 Steel Plate. 16MO3 Steel Plate is one of our top exported products around the world. Our company is ISO 9001:2008. 16MO3 Steel Plate can sustain high pressure and temperature rating. we are largest 16MO3 Steel Plate stockholder in India.
16Mo3 Steel Plate Grade and Specification :
| Thickness | : | 4 mm - 250 mm or as required |
| Width | : | 1000 mm - 2500 mm or as required |
| Length | : | 3000 mm - 12000 mm or as required |
| Standard | : | AISI, ASTM, BS, DIN, GB, JIS |
| Production | : | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Heat Treatment | : | Rolled/Normalised/N+T/QT |
| Dimension range | : | 1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm |
Adopt Standard: EN10028-2
Grade: P235GH, P265GH, P295GH , P355NH, P355N, 16Mo3, P355-NL1, P460NH, P275NH
Equivalent Grades of Grade 16mo3 (1.5415) :
| 16M03 EN 10028-2Number:1.5415 | Comparision of steel grades | |
| DIN 17155 | 15 Mo03 | |
| NFA 36-205 | 15 D3 | |
| UNI 5869 | 15 M0 3 | |
| BS 1501 | 1503 – 243 B | |
| UNE 36087 | 16 Mo 3 | |
| ASTM | A 204 Gr. B | |
| JIS G3115 | - | |
| USA | Germany | Japan | France | England | Italy | Spain | Sweden | Poland | Czechia | Austria | Inter |
| - | DIN,WNr | JIS | AFNOR | BS | UNI | UNE | SS | PN | CSN | ONORM | ISO |
| A204Gr.A | 15Mo3 | STBA12 | 15D3 | 1503-243B | 15Mo3 | 16Mo3 | 2912 | 16M | 15020 | 15Mo3KW | F26 |
| A204Gr.B | 16Mo3 | 240 | 16Mo3 | P26 | |||||||
| 243 | TS26 |
| BS | EN | ASTM/ASME | DIN |
| 1501–243b | 10028-2 | ASTM A204Gr.B | 17155 |
16Mo3 Steel Plate Properties :
Chemical Properties / Chemistry of 16Mo3 Steel Plate :
| Grade | C. (Max) | Mn. | S. | N | Cu | Si. | P. | Cr. | Ni. | Mo. |
| 16Mo3 | 0.12-0.2 | 0.40-0.90 | 0.01 | 0.012 | 0.3 | 0.35 | 0.025 | 0.3 | 0.3 | 0.25-0.35 |
Mechanical Properties of 16Mo3 Steel Plate :
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation in 100-150 mm(%) | Elongation in 16 mm (%) | Max Thickness (mm) |
| 16Mo3 | 440-590 | 220-275 | 19 | 24 | 250 |
16Mo3 Steel Plate Application Industries :
New Arise Metal offers a broad range of 16Mo3 Steel Plate through a worldwide network of stock-keeping branches. These 16Mo3 Steel Plate is use in various industries like:
- Fertilizers Industry
- Aerospace Industry
- Nuclear Power Plant Industry
- Chemical Industry
- Oil & Gas Industry
- Refineries Industry
- Petrochemical Industry
- Paper Industry
Makes of 16Mo3 Plate :
 |  |  |
| Uttam Value Make 16Mo3 Alloy Steel Plates | Essar Make ASTM A204 16Mo3 Chrome Moly Plates | JSPL Make 16Mo3 Pressure Vessel Alloy Steel Plates |
ASME SA 204 16Mo3 Plates Available Thickness, Widths and Lengths :
Thickness | Width | Length |
4 | 2000 | 6000 |
5 | 2000 | 6000 |
6 | 2000 | 6000 |
6 | 2500 | 6000 |
8 | 2000 | 6000 |
8 | 2500 | 6000 |
10 | 2000 | 6000 |
12 | 2000 | 6000 |
15 | 2000 | 6000 |
16 | 2000 | 6000 |
20 | 2000 | 6000 |
25 | 2000 | 6000 |
32 | 2000 | 6000 |
40 | 2000 | 6000 |
50 | 2000 | 6000 |
60 | 1800 | 3400 |
16Mo3 Plate Processing :
The majority of normal processing can be performed on 16Mo3 plate
- Cutting
- Forming Drilling
- Machining
- Grinding
- Testing
New Arise Metal is largest suppliers of 16Mo3 Steel Plate we are supplying 16Mo3 Steel Plate in Saudi Arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa, South America, Brazil, India, Australia, Egypt. we assured our client that we are standing behind our product which we have supplied as well as we issued a quality certificate along with our product which we manufacture supplies and exports
Also Searched as :
| 16MO3 Plates Stockiest | 16MO3 Sheets Stockiest |
| 16MO3 Plates Suppliers | 16MO3 Sheets Suppliers |
| 16MO3 Plates Exporters | 16MO3 Sheets Exporters |
| 16MO3 Plates Stock Holder | 16MO3 Sheets Stock Holder |
| 16MO3 Plates Stockist | 16MO3 Sheets Stockist |
| 16MO3 Uttam Make Plates | 16MO3 Uttam Make Sheets |
| 16MO3 Essar Make Plates | 16MO3 Essar Make Sheets |
| 16MO3 JSPL Make Plates | 16MO3 JSPL Make Sheets |
| 16MO3 1250 X 6000 Plates | 16MO3 1250 X 6000 Sheets |
| 16MO3 2000 X 6000 Plates | 16MO3 2000 X 6000 Sheets |
| 16MO3 2500 X 6000 Plates | 16MO3 2500 X 6000 Sheets |
| 16MO3 2500 X 12000 Plates | 16MO3 2500 X 12000 Sheets |
| 16MO3 Plates Supplier Mumbai | 16MO3 Sheets Supplier Mumbai |
| 16MO3 Plates Supplier Maharashtra | 16MO3 Sheets Supplier Maharashtra |
| 16MO3 Plates Supplier India | 16MO3 Sheets Supplier India |
| 16MO3 Plates Gujarat | 16MO3 Sheets Gujarat |
| 16MO3 Plates with MILL T.C. | 16MO3 Sheets with MILL T.C. |
| Manufacturer of 16MO3 Plates | Manufacturer of 16MO3 Sheets |
| Importer of 16MO3 Plates | Importer of 16MO3 Sheets |
| 16MO3 Steel Plate Distributors | 16MO3 Steel Plate Traders |
Types of Alloy Steel 16MO3 Plates :
| Alloy Steel 16MO3 Plates | 16MO3 plates |
| Alloy Steel ASME SA204 Plates | ASTM A204 16MO3 Plates Exporter |
| Alloy Steel A204 16MO3 Chequered Plate | Alloy Steel 16MO3 Plate Supplier |
| 16MO3 Alloy Diamond Chequered Plate | ASTM A204 16MO3 Plates Manufacturers |
| Alloy Steel 16MO3 Plate Stockholder | Alloy Steel 16MO3 Cold Rolled Plates |
| A204 Alloy Steel Plate 2B Finish Dealer | #4 Finish 16MO3 Alloy Steel Plates |
| Cut to Size Alloy Steel 16MO3 Plates | Hot Rolled Alloy Steel 16MO3 Plates |
| Alloy Steel ASTM A204 CR Plates Stockist | Alloy Steel 16MO3 HR Plates Dealer |
| Leading Manufacturer Of Alloy Steel 16MO3 Plates | ASTM A204 High Quality 16MO3 Plates, |
| ASME SA 204 16MO3 Plates Distributors | 16MO3 Alloy Steel Plates Exporter |
We also Stock Chrome Moly Plate :
- ASTM A 387 Gr. 11 Class 2 Plates
- ASTM A 387 Gr. 12 Class 2 Plates
- ASTM A 387 Gr. 22 Class 2 Plates
- ASTM A 387 Gr. 5 Class 2 Plates
- ASTM A 387 Gr. 9 Class 2 Plates
- ASTM A 387 Gr. 91 Class 2 Plates
- ASME SA 387 Gr. 11 Class 2 Plates
- ASME SA 387 Gr. 12 Class 2 Plates
- ASME SA 387 Gr. 22 Class 2 Plates
- ASME SA 387 Gr. 5 Class 2 Plates
- ASME SA 387 Gr. 9 Class 2 Plates
- ASME SA 387 Gr. 91 Class 2 Plates
- 16Mo3 Plates
- 15Mo3 Plates
