ASTM A516 GRADE 70 PLATES (NACE + HIC) / ASME SA516 GRADE 70 PLATES (NACE + HIC)
If you are also in the search of best quality of ASTM A516 GR. 70 (NACE + HIC) Plate then you have landed on the right place. These plates are used for a long time as they have a long life due to their best and advance manufacturing techniques. These plates are best and ideal for temperature rise work, high pressure and tank fabrication work where accurate & excellent toughness is required for better results. These ASTM A516 GR. 70 (NACE + HIC) Plate are manufactured in accordance with the national and international standards so that they can be accepted worldwide. Due to this, we supply our products to all the leading industries and customers who are satisfied with our production and quality.
All things considered, on the off chance that we discuss the particular for these plates they are made as per both national and global standard and detail that incorporates ASTM A516 GR.70 (NACE + HIC) Plate review. The thickness of these plates fluctuates somewhere around 5 mm to 150 mm while its width shifts from 1500mm to 2500mm or more according to the prerequisite and request of clients. These plates are regularly standardized from 1-1/2 frame and length fluctuates from 6000mm to 12000mm. These plates are accessible in various structures and shapes that incorporate standards, cleaned plates, shim plates, chilly moved plates, hot moved plates and weight vessel plates. The plates are accessible with reflect, emblazoned and hairline surface.
There are different applications where these plates are utilized, for example, control age, gas preparing, oil boring organizations, warm exchangers, condensers, petrochemicals, and seawater hardware. These plates are produced with appropriate care and under the direction of value specialists and utilizing all around tried material which makes these plates to withstand effectively in raised condition and temperature. The grade of this plate is ASTM A516 GR.70 (NACE + HIC) Plate which specifies its condition of tensile strength, length, and sizes.
Have you at any point seen how these plates manage their quality and strength for quite a while? If not, at that point take note of that these plates run over different tests and assessments that assistance the producer to check the nature of plates. These tests are smoothing test, hardness test, smaller scale and large-scale test, IBR test, process test, ultrasonic test and then some. With it, producers offer different authentications like plant test declaration, hardness test testament and outsider examination report.
The most vital thing that issues the most to a client is items bundling. ASTM A516 GR. 70 (NACE + HIC) Plate is produced by driving makers; along these lines, they keep a legitimate mind the bundling procedure. To keep these plates from harms of rusting they pack these plates in best nature of wooden cases or boxes with the goal that they won't get rust or get harmed at the season of transportation and until its last phase of generation. Moreover, at the time bundling, finish stamping of the item is portrayed over the crate that incorporates the item name, size, length, and particular.
SA516 Grade 70 NACE Plate Distributors, ASME SA516 GR. 70 HIC Plate, ASTM A516 GR. 70 HIC Nace Tested Plates Stockholders in Gujarat, A516 Gr 70 NACE and HIC Boiler Quality Steel Plate, Hot Rolled Steel ASTM A516 Gr 70 NACE + HIC Plates.
ASTM A516 Gr 70 Carbon Steel (NACE + HIC) Plate Specification :
- Width:1000mm-4500mm
- Thickness:5mm-150mm
- Length:3000mm-18000mm
- Supply Condition:As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
- Impact tested:-52° C
- Tempering:Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
- Applications:used in both pressure vessels and industrial boilers.
- Process of Manufacturing:Hot-Rolled (HR)
(NACE + HIC) ASTM A516 Gr.70 Steel Plate Equivalent Standard :
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 - Grade 70 | - |
ASTM A516 Grade 70 (NACE + HIC) Plate Chemical Composition :
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V | C.E. |
| 0.10/ 0.22 | 0.6 | 1/ 1.5 | 0.01 | 0.002 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 0.420 (max) |
SA516 Grade 70 HIC + NACE Plate Mechanical Properties :
| Tensile strength MPa (ksi) | Yield strength MPa (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 490-260 (70-90) | 265 (38) | 17 | 21 |
NACE and HIC Tested ASTM A516 GR. 70 Steel Plate Makes :
 |  |  |  |
| Essar Make A516 GR.70 (NACE + HIC) Steel Plate | Jindal Steel Make ASTM A516 GR. 70 HIC NACE Plate | Welspun Make NACE HIC ASTM A516 Grade 70 Plate | SAIL Make ASTM A516 Grade 70 (NACE + HIC) Plate |
 |  |  | |
| Posco Make ASTM A516 Gr.70 (NACE + HIC) Plate | ArcelorMittal Make ASTM A516 Gr.70 NACE HIC Plate | Dillinger Make ASTM A516 Gr.70 (NACE + HIC) Plate |
